57mm 36V 4000RPM Brushless Dc Gear Motor 138W 150W With Gearbox
Ratio 3:1 - 100:1
BLDC motors offer high efficiency and controllability, and that
they have a long operating life. They are widely used in devices
that run continuously. They have long been used in washing
machines, air conditioners, and other consumer electronics; and
more recently, they are appearing in fans, where their high
efficiency has contributed to a significant reduction in power
consumption.
1.Product Specification:
| Model | Voltage | Rated Speed | Rated Torque | Rated Current | Rated
Power | Peak Torque | Torque constant | Body length | Mass |
| VDC | Rpm | N.m | Amps | W | N.m | N.m/A | L:mm | Kg |
| 57BL55-230 | 24 | 3000 | 0.16 | 3.5 | 50 | 0.48 | 0.046 | 55 | 0.46 |
| 57BL75-230 | 24 | 3000 | 0.32 | 7 | 100 | 0.96 | 0.046 | 75 | 0.75 |
| 57BL95-230 | 24 | 3000 | 0.48 | 10.5 | 150 | 1.44 | 0.046 | 95 | 1 |
| 57BL115-230 | 24 | 3000 | 0.64 | 13.9 | 200 | 1.92 | 0.046 | 115 | 1.2 |
We are set motor and drive production as one of the manufacturers,
while providing motor, we also provide the corresponding model of
drive products, and have technical support.
2.Company introduction:
Changzhou Hejie Motor Co., Ltd. is located in the rich rao
beautiful developed China motor town -- Changzhou city, founded in
2009, is specialized in research and development, production, sales
of motor an enterprise. The company has accumulated more than ten
years of experience in motor design and manufacturing, and has a
number of invention patents and utility model patents. The company
mainly r & D and production series stepper motor, the series
brushless DC motor, AC/DC servo motor. The motor sells well all
over the country and is exported to more than ten countries and
regions. The products have passed CE and ROHS certification, and
the company has passed ISO9001 total quality management system
certification. Company products are widely applied to carved
machine, embroidery machine, industrial robots, robots, unmanned
aerial vehicle (uav), CNC machine tools, digital printing, computer
flat knitting machine, 3 d printing, packaging machinery,
industrial printers, medical equipment, new energy vehicles and
other automation control and automation equipment in the system.
Production equipment:
Related Qualification Certificate:
3.FAQ
Q1:Are you manufacturer ?
A1:Yes, we are the manufacturer of gear motor and planetary gearbox.
Q2 : What specifications we need before you place an order?
A2 : Rated torque, Rated speed, IP Grade, mounting dimensions.
Q3 : What is the price ?
A3 : Price always depends on quantity, we offer range pricing
Q4 : Is it customized ?
A4 : Yes, different clients have different requirements, so we customize for you. .
