500W Air-Cooled Spindle Motor Mach3 ER11 DC 48V 0.44N.M For CNC
All series brushless motor including: 57 #, 60 #, 42 #, 80 #, 86 #,
110 #, are widely used in electronic digital, printers, fax
machines, manipulators, etc.
1.Dimension:
2. Genaral Specification of air-cooled spindle motor
| Item | Specification |
| Winding type | Star |
| Hall effect angle | 120 degree electrical angle |
| Shaft run out | 0.025mm |
| Radial play | 0.02mm＠450g |
| End play | 0.08mm＠450g |
| Max.radial force | 75N ＠20mm form the flange |
| Max.axial force | 15N |
| Insulation class | Class B |
| Dielectric strength | 500VDC for one minute |
| Insulation resistance | 100MΩ Min.,500VDC |
3.Specification of brushless DC motor:
| | Model |
| Specification | Unit | HJ57BLS005 | HJ57BLS01 |
| Number Of Phase | Phase | 3 |
| Number Of Poles | Poles | 4 |
| Rated Voltage | VDC | 36 |
| Rated Speed | Rpm | 4000 |
| Rated Torque | N.m | 0.33 | 0.44 |
| Rated Current | Amps | 5.3 | 6.8 |
| Rated Power | W | 138 | 184 |
| Peak Torque | N.m | 1 | 1.32 |
| Peak Current | Amps | 15.5 | 20.5 |
| Back E.M.F | V/Krpm | 7.3 | 7.1 |
| Torque Constant | N.m/A | 0.07 | 0.068 |
| Rotor Inertia | g.c㎡ | 173 | 230 |
| Body Length | mm | 87 | 107 |
| Weight | Kg | 1 | 1.25 |
| Sensor | Honeywell |
| Insulation Class | B |
| Degree of Protection | IP30 |
| Storage Temperature | -25～+70℃ |
| Operating Temperature | -15～+50℃ |
| Working Humidity | 85% or under 85% RH(non condensing) |
| Working Environment | outdoor(no direct sunlight),Non-corrosive Gas,
Non-inflammable gas, No oil fog, No dust |
| Altitude | 1000m or under 1000m |
